Concealed thermostatic shower valve trim with one outlet and two lever handles, for Crosswater’s Crossbox rough-in body (sold separately). Works from 0.5 bar, 1/2″ connections, WRAS and TMV2 approved, 15-year guarantee.
€312.99
In stock
Order today and receive it on October 27 - November 2 in Spain, or on November 2-4 in the EU and the United Kingdom.
Secure payment with Visa, Mastercard and American Express. Prices include VAT.
Spain 2–7 business days, rest of the European Union and the United Kingdom 6–8. Orders confirmed on a business day before 14:00 are prepared the same day. See Shipping and Payment Methods.
Free when the product is faulty, arrives damaged or does not match the order. If you simply change your mind, the return costs £34.90 from the United Kingdom and €24.90 from Ireland and the rest of the European Union, and is free within Spain; the product must not have been installed or used. See Returns, Exchanges and Warranty.
Every product is new and sealed. 3-year legal guarantee; the manufacturer’s commercial warranty applies in addition where it exists. Customer support in Spanish and English, Monday to Friday.
This MPRO valve is the chrome 1-outlet trim set for Crosswater’s Crossbox universal concealed body, which is sold separately (code CROSSBOX): one lever sets the temperature thermostatically and the other turns the flow on and off, feeding a single fixed head or a slide-rail kit (sold separately). The trim and the Crossbox body are brass, with ceramic-disc flow control. Because the Crossbox stays in the wall, the visible trim can be changed later without re-plumbing, and a flush-block plate allows pressure testing before tiling.
The valve suits all plumbing systems from 0.5 bar (Crosswater) up to 5 bar (3 bar recommended), with 1/2″ connections; the Crossbox needs only 60 mm minimum depth and can be front- or rear-mounted. The trim plate measures 130 × 180 mm and projects 73 mm from the finished wall (122 mm overall depth with the body). Plan the wall build-up and access before tiling and check that the Crossbox body and the chosen shower head or kit are ordered separately.
The figures on this page are taken from the manufacturer’s own documentation and product data; if anything differs, the manufacturer’s documentation prevails. The manufacturer gives a 15-year guarantee, which applies in addition to your statutory consumer rights.
| Brand | Crosswater |
|---|---|
| Model | MPRO Crossbox 1000 valve, 1 outlet |
| MPN / Manufacturer code | PROCB1000LBPC |
| EAN / GTIN | 5055833688449 |
| Finish / Colour | Chrome |
| Product type | Concealed shower valve |
| Application | Shower |
| Operation | Manual / thermostatic |
| Number of ports / outlets | 1 |
| Body material | Brass |
| Max water pressure | 5 bar |
| Min water pressure | 0.5 bar |
| Connection size | G 1/2" (inlets and outlet, on the Crossbox Universal Box) |
| Connection type | BSP female |
| Power source | None |
| Width | 130 mm |
| Height | 180 mm |
| Depth | 122 mm |
| Weight | 4.62 kg |
| Installation type | Concealed in wall |
| Mounting notes | Crossbox min. 60 mm installation depth, front or rear mounting; trim projects 73 mm |
| Included in box | Crossbox 1-outlet trim set: flow control, thermostat, backplate and two lever handles (must be installed on the Crossbox Universal Box, code CROSSBOX, sold separately) |
| Approvals | WRAS (Crossbox approval 2501751), TMV2 |
| Guarantee | 15 years |
